AMSOIL PC Series Synthetic Compressor Oil is a long-life,
premium compressor lubricant based on novel, proprietary technology. It incorporates the highest quality, thermally stable synthetics fortified with premium non-detergent additives for maximum protection at high temperatures. It lasts up to 8,000 hours, effectively reducing maintenance and waste oil disposal costs.
AMSOIL PCK is ISO 100, SAE 40
Package sizes include:
1-Quart Bottle
5-Gallon Pail
55-Gallon Drum
275-Gallon Tote
AMSOIL PC Series Oil in the appropriate viscosity is recommended for use in single and multistage rotary screw, vane, centrifugal and reciprocating compressor crankcases and cylinders, vacuum pumps, pressure washer pumps and other applications such as gears, bearings, blowers and pumps. In compressor applications, drain intervals of 8,000 hours or more can be expected under normal operation. Drain intervals are subject to operating conditions and maintenance practices. Monitoring by oil analysis is recommended. For best performance when converting to AMSOIL PC Series Oil, it is recommended the compressor be flushed of the old oil and all filters changed prior to the installation of PC Series Oil. If carbon deposits are present on the internal components, it is recommended they be removed following the compressor manufacturer recommendations.
*
Consult the equipment manufacturer or AMSOIL Technical Services for use in specific applications.
| Synthetic PC Series Compressor Oils | PCH ISO 32 SAE 10W | PCI ISO 46 SAE 20 | PCJ ISO 68 SAE 30 | PCK ISO 100 SAE 40 |
| ROTARY COMPRESSOR | ||
| PRODUCT | VISCOCITY | FLUID LIFE |
| PCH,PCI,PCJ | 32-68 | Up to 8000 hours at 200F discharge |
| RECIPROCATING COMPRESSOR | ||
| PRODUCT | VISCOCITY | STAGES |
| PCJ,PCK | 68-100 | SINGLE PISTON, SINGLE STAGE VACUUM PUMP |
The correct viscosity grade compressor oil is recommended for use in rotary screw, rotary vane, reciprocating and other compressor applications. Compatible with PAO, ester- and petroleum-based compressor oils. Not compatible with glycol- or silicone-based compressor oils.
Improves Compressor Efficiency| COMPATIBILITY | |
Gases: | • Nitrogen • Hydrogen • Helium • Carbon Monoxide • Carbon Dioxide (dry) • Ethylene • Methane • Propane • Butane • Propylene • Butylenes • Natural Gas • Benzene • Butadiene • Furnace (crack gas) • Hydrogen Sulfide (dry) • Synthetic Gas • Sulfur Dioxide. |
Paints: | • Epoxy • Oil Resistant Alkyd • Acrylic Enamel. |
Plastics: | • Acetal (Delrin) • ABS • Phenolic • Polyamide-imide • Polyamide (Nylon) • Polycarbonate (metal covered only) • Polyester • Polyetherimide (Nylon) • Polyimide • Polyphenylene oxide • Polystyrene • Polysulfone • PTFE (Teflon) • Terephthalate. |
Elastomers: | • Fluoroelastomer (Viton) • Nitrile (Buna N) • Polyacrylate • TFE/P • Poly Urethane. |
| Note: Not recommended for “breathing air” or refrigeration compressors. Not recommendedfor use with polycarbonate plastic that is not metal covered, PVC plasticand butyl, ethylene-propylene or SBR rubber. PC Series Oils are NotCompatible with polyalkylene glycol or silicone oils. | |
This product is not expected to cause health concerns when used for the intended application and according to the recommendations in the Material Safety Data Sheet (MSDS).
Click here to view the MSDS Data Sheet for AMSOIL PCK.
Keep out of the reach of children. Don't pollute. Return used oil to collection centers.
| Synthetic PC Series Compressor Oils | SAE 10W (PCH) | SAE 20 (PCI) | SAE 30 (PCJ) | SAE 40 (PCK) |
| ISO VG - ASTM D-2422 | 32 | 46 | 68 | 100 |
| VK 100°C - ASTM D-445 | 6.1 | 7.3 | 10.5 | 13.4 |
| VK 40°C - ASTM D-445 | 32.8 | 43.0 | 68.1 | 100.2 |
| Viscosity Index - ASTM D-2270 | 135 | 132 | 138 | 133 |
| SPGR - ASTM D-1298 | 0.8499 | 0.8529 | 0.8597 | 0.8550 |
| Density - ASTM D-1298 | 6.989 | 7.018 | 7.098 | 7.119 |
| Flash Point °C (°F) - ASTM D-92 | 260 (500) | 252 (486) | 250 (482) | 262 (504) |
| Fire Point °C (°F) - ASTM D-92 | 274 (525) | 276 (529) | 276 (529) | 274 (525) |
| Pour Point °C (°F) - ASTM D-97 | -53 (-63) | -47 (-53) | -40 (-40) | -44 (-47) |
| Four-Ball Wear Test - ASTM D-4172 (40 kg, 1200 rpm, 75° C, 60 min.) | 0.45 | 0.45 | 0.45 | 0.45 |
| Copper Strip Corrosion Test - ASTM D-130 | 1A | 1A | 1A | 1A |
| Rust Test - ASTM D665 A & B Fresh Water and Synthetic Sea Water | Pass | Pass | Pass | Pass |
| Foam, ml (ASTM D-892) Sequence I, II, III Test End - and After 10 minutes settling | 0/0/0 | 0/0/0 | 0/0/0 | 0/0/0 |
| Demulsibility ASTM D-1401 [oil/water/cuff (minutes)] | 40/40/0 (10) | 40/40/0 (10) | 40/40/0 (5) | 40/40/0 (10) |
Product Name: PC Series Compressor Oil (PCK) ISO 100, SAE 40
Current Rating: 3.86out of 5 stars
Votes & Reviews: 7 vote(s) and 1 user reviews.
Re: Compressor seems to run hot
Thanks for the review. Please be advised that it is not recommended to run 50% lower viscosity than recommended. It is like using a 5W20 in a motorcycle requiring 10W40 motor oil.
Replied by Tech Admin
On the upside, AMSOIL's robust base oils will withstand extreme heat and will not sludge or cause accelerated wear.
Canada
United States
Reviewed by fishnguy:
Compressor seems to run hot
When I used this oil in my Porter Cable air compressor, it seemed to run hotter than when I used another brand of ISO 150 compressor oil. AMSOIL doesn't make a heavier compressor oil so I will use the ISO 150 oil in my compressor during the spring, summer and fall. I use AMSOIL ISO 46 oil in my compressor in the winter.
